iFlight Nazgul5 V2 6S Analog 240mm BLITZ F7 Flight Controller 45A SucceX-E ESC 5 Inch Freestyle FPV Racing Drone BNF PNP w/ 5.8g 800mW VTX
Short content about your product.
Short content about your product.
Icons are optional
USE RICH TEXT EDITOR
And big icons to highlight the product sale point
Specfication:
Brand: iFlight
Item Name: Nazgul5 V2 Analog 6S Freestyle FPV Racing Drone
|
FC // BLITZ F7 Flight Controller V1.1 |
MCU: STM32F722 216MHz Gyro: MPU6000 OSD Chip: IFLIGHTOSD（AT7456E） Flash: 16MB (Blackbox flash) UARTS: 6 Motor outputs: 4x (SH1.0 connector) I2C serial: SDA / SLA pads Smartaudio / IRC Tramp VTX protocol supported LED controller: Yes Beeper pad: Yes Firmware target: IFLIGHT_SUCCEX_E_F7 Mount pattern: 30.5*30.5mm / 4mm PCB hole diameter Dimensions: 36*36 mm Weight: 6.9g |
|
ESC // SucceX-E 45A 2-6S BLHeli_S 4-in-1 ESC |
Dimension: 54*45mm Constant: 45A / Burst: 50A |
|
XING-E 2207 1800KV Motor |
2207 1800KV 6S Motor |
|
VTX// SucceX Force 5.8g 800mW VTX Adjustable |
The output power is stable; Transmit power 4 gear switch: 25mW/200mW/400mW/800mW; Output 48 frequency points, Frequency lock fast, the boot does not interfere with companions; Built-in output power self-check function; Full format video format: NTSC /PAL; Wide input voltage range. low power consumption: 7V～36V， 12V/380mA@800mW; Small size:36*36*3mm Mounting holes 4-M3 Lightweight: 7.2g(excluding antenna) |
Recommended parts: ( NOT Included)
6S 1300mAh Lipo Battery
Package Included:
1x Nazgul5(XL5 V5) Frame
1x RaceCam R1 Mini 1200TVL 2.1mm 19*19
1x Albatross RHCP SMA 5.8g antenna
2sets x Nazgul 5 inch 3-blades (Set of 4 - Color may vary)
1x 20*200mm Microfiber PU Leather Battery Strap (Color May Vary)
1x 20*250mm Microfiber PU Leather Battery Strap (Color May Vary)
